MANLEY FORD 4.6L MODULAR AND 5.0L COYOTE I-BEAM ROD WITH ARP2000 ROD BOLTS
Mfr part # 14518-8 · Livernois SKU MAN14518-8 · Wheels & Tires
Description
Manley Pro Series “I” Beam Rods are forged from 4340 aircraft quality vacuum degassed material. Utilizing a proven Lightweight yet rugged design and ARP 2000 cap screws, they are properly shot peened after machining and 100% magnafluxed.
On all Manley connecting rods, sets are weight matched to ą 1.5 grams, big and small end bores are final honed to a tolerance of a .0002″, critical bend and twist attributes are held to a minimum, and exacting attention is paid to every detail by our final inspection department; thus rendering a finished product that is second to none.
About Livernois Motorsports
Livernois Motorsports & Engineering has become best-known for revolutionary tuning and high-end performance products for late model Ford, Mopar and GM vehicles. The company is proud of its deep roots in the automotive and motorsports industry dating back to its original founding in 1949. Since then the company has expanded its product line to include tuning and performance components for desert racing, SCCA and drag racing. Livernois Motorsports is proud to engineer, test and manufacture its products in the USA.
Manufacturer part number 14518-8.
Product Information
4.6L MODULAR / 5.0L DOHC COYOTE V-8 I-BEAM
Manley’s signature design combines the appropriate weight and rugged strength for ultimate horsepower applications. Each rod is shot peened after machining and magnafluxed. Bores are held to exacting tolerances. Bend and twist is tightly controlled. Cap fasteners are ARP 2000 alloy cap screws. Heavier beam for forced induction applications.
- Forged from 4340 or 300M aircraft quality vacuum degassed material
- Fully machined to produce the lightest and strongest rod possible
- Shot peened after machining to MIL spec and 100% individually magnafluxed
- Cap fasteners are 7/16” ARP 2000 or optional ARP 625+ cap screws
- Flywheel horsepower range is 900+ HP – Oval Track, 1200+ HP – Drag Race
Rod Length – 5.933″
Rod Journal – 2.239″
Pin Diameter – 0.866″
Vehicle Fitment 117 applications
Ford (76)
- 1992–2008 Crown Victoria 4.6L V8
- 1992–2011 Crown Victoria 4.6L V8
- 1992–2005 Crown Victoria 4.6L V8
- 1992 Crown Victoria 4.6L V8
- 1993–2011 Crown Victoria 4.6L V8
- 1994–1997 Thunderbird 4.6L V8
- 1996–2010 Mustang 4.6L V8
- 1996–1999 Mustang 4.6L V8
- 1997–2002 E-150 4.6L Triton V8
- 1997–2000 E-150 4.6L Triton V8
- 1997–2002 E-150 4.6L Triton V8
- 1997–2000 E-150 4.6L Triton V8
- 1997–2002 E-150 4.6L Triton V8
- 1997–2004 Expedition 4.6L Triton V8
- 1997–2004 Expedition 4.6L Triton V8
- 1997–2000 F-150 4.6L Triton V8
- 1997–2003 F-150 4.6L Triton V8
- 1997–2010 F-150 4.6L Triton V8
- 1997–2010 F-150 4.6L Triton V8
- 1997–1999 F-250 4.6L Triton V8
- 1997–1999 F-250 4.6L Triton V8
- 1997–1999 F-250 4.6L Triton V8
- 1997–1999 F-250 4.6L Triton V8
- 2001–2002 E-150 4.6L Triton V8
- 2001–2003 F-150 4.6L Triton V8
- 2001 Mustang 4.6L V8
- 2001 Mustang 4.6L V8
- 2002–2009 Crown Victoria 4.6L V8
- 2002–2010 Explorer 4.6L V8
- 2002–2010 Explorer 4.6L V8
- 2002–2010 Explorer 4.6L V8
- 2003–2014 E-150 4.6L Triton V8
- 2003–2005 E-150 4.6L Triton V8
- 2003–2005 E-150 4.6L Triton V8
- 2003–2005 E-150 4.6L Triton V8
- 2003–2014 E-250 4.6L Triton V8
- 2003–2004 Mustang 4.6L V8
- 2003–2004 Mustang 4.6L V8
- 2003 Mustang 4.6L V8
- 2004–2006 Crown Victoria 4.6L V8
- 2004 Expedition 4.6L Triton V8
- 2004 Expedition 4.6L Triton V8
- 2004 Expedition 4.6L Triton V8
- 2004 Explorer 4.6L V8
- 2004–2005 Explorer 4.6L V8
- 2004–2010 F-150 4.6L Triton V8
- 2004 F-150 4.6L Triton V8
- 2004 F-150 4.6L Triton V8
- 2005 Crown Victoria 4.6L V8
- 2006–2009 Crown Victoria 4.6L V8
- 2006–2007 E-150 4.6L Triton V8
- 2006–2014 E-150 4.6L Triton V8
- 2006–2014 E-150 4.6L Triton V8
- 2007–2010 Explorer 4.6L V8
- 2007–2010 Explorer 4.6L V8
- 2007–2008 Mustang 4.6L V8
- 2008 F-150 4.6L Triton V8
- 2008 F-150 4.6L Triton V8
- 2008–2009 Mustang 4.6L V8
- 2010–2011 Crown Victoria 4.6L V8
- 2010 F-150 4.6L Triton V8
- 2011–2014 F-150 5.0L Coyote V8
- 2011–2014 F-150 5.0L Coyote V8
- 2011–2022 F-150 5.0L Coyote V8
- 2011–2022 F-150 5.0L Coyote V8
- 2011–2022 F-150 5.0L Coyote V8
- 2011–2014 F-150 5.0L Coyote V8
- 2011–2022 F-150 5.0L Coyote V8
- 2011–2022 F-150 5.0L Coyote V8
- 2011–2022 Mustang 5.0L Coyote V8
- 2012–2013 Mustang 5.0L Coyote V8
- 2015 Mustang 5.0L Coyote V8
- 2015–2022 Mustang 5.0L Coyote V8
- 2016–2022 F-150 5.0L Coyote V8
- 2019–2020 Mustang 5.0L Coyote V8
- 2021–2022 Mustang 5.0L Coyote V8
Lincoln (29)
- 1991–1999 Town Car 4.6L V8
- 1991–2003 Town Car 4.6L V8
- 1991–1995 Town Car 4.6L V8
- 1991–2010 Town Car 4.6L V8
- 1991–2007 Town Car 4.6L V8
- 1991–1995 Town Car 4.6L V8
- 1993–1995 Mark 4.6L V8
- 1993 Town Car 4.6L V8
- 1994 Town Car 4.6L V8
- 1995 Continental 4.6L V8
- 1995 Continental 4.6L V8
- 1995–1997 Continental 4.6L V8
- 1995–1998 Mark 4.6L V8
- 1996 Continental 4.6L V8
- 1996 Mark 4.6L V8
- 1996 Town Car 4.6L V8
- 1997–1998 Mark 4.6L V8
- 1997 Town Car 4.6L V8
- 1998–2002 Continental 4.6L V8
- 2001–2003 Town Car 4.6L V8
- 2001–2011 Town Car 4.6L V8
- 2003–2005 Aviator 4.6L V8
- 2003 Town Car 4.6L V8
- 2004–2006 Town Car 4.6L V8
- 2004 Town Car 4.6L V8
- 2004 Town Car 4.6L V8
- 2005–2011 Town Car 4.6L V8
- 2005–2011 Town Car 4.6L V8
- 2006–2007 Town Car 4.6L V8
Mercury (12)
- 1992–2008 Grand Marquis 4.6L V8
- 1992–2011 Grand Marquis 4.6L V8 (2V)
- 1994–1997 Cougar 4.6L V8
- 2002–2004 Mountaineer 4.6L V8
- 2003 Grand Marquis 4.6L V8
- 2003–2004 Marauder 4.6L V8
- 2004–2010 Mountaineer 4.6L V8
- 2005 Grand Marquis 4.6L V8
- 2005 Grand Marquis 4.6L V8
- 2005 Grand Marquis 4.6L V8
- 2005 Mountaineer 4.6L V8
- 2005–2006 Mountaineer 4.6L V8
